The outdoor cabinet series provides highly reliable and enclosed outdoor site solutions for outdoor FTTC/FTTH/ transmission scenarios. The products support installation on a wall, pole, pedestal, and elevated platform.
Product Details
Place of Origin: Guangdong, China
Brand Name: for HUAWEI
Model Number: ESC30-N1
Payment & Shipping Terms
Minimum Order Quantity: 2 sets
Price: $899.00 - $1,199.00/sets
Type: |
Telecom Power |
Use: |
Base Station Communication |
Product Name: |
PowerCube 500 For HUAWEI ESC30-N1 |
Output Voltage: |
32-58 |
Output Current: |
8.34 |
Output Power: |
400 |
Input Voltage: |
170-265AC |
Application Scope: |
Base Station Communication |
Protection Level: |
IP55 |
Application: |
Outdoor |
Dimensions: |
380mm (width) * 480mm (depth) * 750mm (height) |
Type: |
Telecom Power |
Use: |
Base Station Communication |
Product Name: |
PowerCube 500 For HUAWEI ESC30-N1 |
Output Voltage: |
32-58 |
Output Current: |
8.34 |
Output Power: |
400 |
Input Voltage: |
170-265AC |
Application Scope: |
Base Station Communication |
Protection Level: |
IP55 |
Application: |
Outdoor |
Dimensions: |
380mm (width) * 480mm (depth) * 750mm (height) |
Battery | -48 V;150 Ah Max | |
Battery Charging | - .48 V;15 A Max | |
Battery Discharging | 48 V; 7.5 A Max | |
Heat dissipation form | natural heat dissipation | |
Battery capacity | Supports up to 2 sets of 75Ah lithium batteries | |
Environmental features | ||
Permissible operating temperature | -33℃～+40℃ | |
Permissible storage temperature | -33℃～+40℃ | |
Protection (rectifier) | ||
Protection level | IP55 | |
