Product Details
Place of Origin: Guangdong, China
Brand Name: other
Model Number: RTN380AX
Payment & Shipping Terms
Minimum Order Quantity: 2 units
Price: $4,800.00/units 2-9 units
Packaging Details: carton
Supply Ability: 8000 Unit/Units per Day
Type: |
Wireless IP Microwave |
Use: |
Mountainous Plains, Lakes, And Islands |
Warranty Time: |
1 Year |
Network: |
Wireless Lan, TCP, Ip, POE |
Product Name: |
Wireless IP Microwave |
Application: |
Mountainous Plains, Lakes, And Islands |
Color: |
White |
Model: |
RTN380AX |
Code: |
52451252 |
T/R Interval: |
10GHz |
High Station: |
52451251 |
Low Station: |
52451252 |
High Station Transmission Frequency: |
81 86GHz |
Low Station Transmission Frequency: |
71 76GHz |
Port: |
Tianjin |
Type: |
Wireless IP Microwave |
Use: |
Mountainous Plains, Lakes, And Islands |
Warranty Time: |
1 Year |
Network: |
Wireless Lan, TCP, Ip, POE |
Product Name: |
Wireless IP Microwave |
Application: |
Mountainous Plains, Lakes, And Islands |
Color: |
White |
Model: |
RTN380AX |
Code: |
52451252 |
T/R Interval: |
10GHz |
High Station: |
52451251 |
Low Station: |
52451252 |
High Station Transmission Frequency: |
81 86GHz |
Low Station Transmission Frequency: |
71 76GHz |
Port: |
Tianjin |
classification | Wireless transmission | ||||||
Frequency band | 71 ~ 86 GHz | ||||||
TR frequency interval | 10G MHz | ||||||
Bandwidth | 5000M | ||||||
ATPC adjustment step | Adjust the upper and lower thresholds based on the actual received power and ATPC The difference between the center values is automatically adjusted, with a single maximum Adjust the step to 10dB, with a minimum adjustment step of 1dB | ||||||
ATPC maximum adjustment speed | 30dB/s | ||||||
ATPC automatic threshold enable | support | ||||||
version | V100R009C10/V100R020 | ||||||
ATPC adjustment | If the actual transmission power of the sending end reaches the set maximum transmission power The power will not be adjusted at this time. The maximum transmission power set does not exceed the limit of OptiX RTN 380AX Set the maximum transmission power. If the maximum transmission power is not set, the transmission power will increase to After the rated maximum transmission power of OptiX RTN 380AX, it cannot Adjust upwards again. | ||||||
AMAC | AMAC can be used in conjunction with ATPC, but it is generally not recommended Sample use. If it needs to be used in conjunction, the following precautions should be taken: Set the threshold under ATPC to be greater than the planned full capacity modulation mode for flexibility Sensitivity plus at least 14dB. Set the ATPC upper threshold to the lower threshold value plus at least 5dB. | ||||||
XPIC | XPIC can be used in conjunction with ATPC, but this is generally not recommended Use. If it needs to be used in conjunction, the following precautions should be taken: A set of XPIC horizontal polarization direction links and vertical polarization direction links The same ATPC parameters should be configured (ATPC enable, ATPC adjustment door Limit). Set the difference between the upper and lower thresholds of ATPC as small as possible, with a recommended value of 5dB. | ||||||
Antenna | Parabolic antenna: 0.3m~0.6m | ||||||
Power supply | -38.4 V~-57.6 V | ||||||
