Product Details
Place of Origin: Guangdong, China, guangdong, China
Brand Name: HW
Model Number: CloudEngine 16804, CloudEngine 16808, CloudEngine 16816, CloudEngine S5755-H Series
Payment & Shipping Terms
Minimum Order Quantity: 2 pieces
Price: $5,999.00 - $32,000.00/pieces
Packaging Details: 1,Carton packing or wooden case packing according to customer requirements
2,Sufficient protective materials are added to the packing box to effectively prevent the product from being damaged due to turbulence during transportation.
Supply Ability: 1000 Carton/Cartons per Day
Private Mold: |
NO |
Products Status: |
Stock, Stock |
Ports: |
≥ 48 |
Transmission Rate: |
10/100/1000Mbps |
Function: |
LACP, QoS, SNMP, Stackable, VLAN Support, SNMP, VLAN Support |
Communication Mode: |
Full-Duplex & Half-Duplex |
Switch Capacity: |
1548Tbps |
Product Description: |
8x10/100/1000Base-T Ethernet Port, 4 10 Gigabits SFP+ |
Switching Capacity: |
1548Tbps |
Rack Units: |
1RU |
Warranty: |
1 Years |
Condition: |
100% Brand New 88036UML N1-CE168LIC-SEC N1 |
Private Mold: |
NO |
Products Status: |
Stock, Stock |
Ports: |
≥ 48 |
Transmission Rate: |
10/100/1000Mbps |
Function: |
LACP, QoS, SNMP, Stackable, VLAN Support, SNMP, VLAN Support |
Communication Mode: |
Full-Duplex & Half-Duplex |
Switch Capacity: |
1548Tbps |
Product Description: |
8x10/100/1000Base-T Ethernet Port, 4 10 Gigabits SFP+ |
Switching Capacity: |
1548Tbps |
Rack Units: |
1RU |
Warranty: |
1 Years |
Condition: |
100% Brand New 88036UML N1-CE168LIC-SEC N1 |
Technical Specifications | CloudEngine 16804 | CloudEngine 16808 | CloudEngine 16816 |
Depth [mm] | 985 mm | 985 mm | 1144 mm |
Chassis height | 9.8 | 15.8 | 32.3 |
Wide [mm] | 483 mm | 483 mm | 483 mm |
Height [mm] | 438 mm | 703 mm | 1436 mm |
Weight with packaging | 138 (304.29) | 177 (390.29) | 335 (738.68) |
Weight without packaging | 94.1 kg (207.49 lb) (including two MPUs and filler panels) | 129.8 kg (286.21 lb) (including two MPUs and filler panels) | 262.8 kg (579.47 lb) (including two MPUs and filler panels) |
Heat dissipation mode | Heat dissipation using fans | Heat dissipation using fans | Heat dissipation using fans |
Power supply mode | AC,HVDC | AC,HVDC | AC,HVDC |
Rated input voltage [V] | AC: 220 V; 50 Hz/60 Hz High-voltage DC (HVDC): 240 V/380 V | AC: 220 V; 50 Hz/60 Hz High-voltage DC (HVDC): 240 V/380 V | AC: 220 V; 50 Hz/60 Hz High-voltage DC (HVDC): 240 V/380 V |
Input voltage range [V] | AC: 176–290 V; 45–65 Hz High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V | AC: 176–290 V; 45–65 Hz High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V | AC: 176–290 V; 45–65 Hz High-voltage DC (HVDC): 188 V to 288 V or 260 V to 400 V |
Maximum input current [A] | AC: 16 A @ 200 V; 18.5 A @ 176 V High-voltage DC (HVDC): 18 A @ 188 V; 13 A @ 260 V | AC: 16 A @ 200 V; 18.5 A @ 176 V High-voltage DC (HVDC): 18 A @ 188 V; 13 A @ 260 V | AC: 16 A @ 200 V; 18.5 A @ 176 V High-voltage DC (HVDC): 18 A @ 188 V; 13 A @ 260 V |
Maximum output power [W] | In 5+1 backup mode: 3000 W x 5 = 15000 W In 6+0 backup mode: 3000 W x 6 = 18000 W | In 9+1 backup mode: 3000 W x 9 = 27000 W In 10+0 backup mode: 3000 W x 10 = 30000 W | In 19+1 backup mode: 3000 W x 19 = 57000 W In 20+0 backup mode: 3000 W x 20 = 60000 W |
Redundant fans | Fan modules work in hot standby mode. At the normal temperature range, the system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. | Fan modules work in hot standby mode. At the normal temperature range, the system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. | Fan modules work in hot standby mode. At the normal temperature range, the system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. |
Redundant power supply | Dual-input power supply system: N+1 backup is recommended. Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability. | Dual-input power supply system: N+1 backup is recommended. Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability. | Dual-input power supply system: N+1 backup is recommended. Single-input power supply system: N+1 backup Dual-input power supply is recommended to ensure reliability. |
Redundant Switch fabrics | N+M | N+M | N+M |
Redundant MPUs | 1:01 | 1:01 | 1:01 |
Number of power modules | 6 | 10 | 20 |
Airflow direction | Front-to-back airflow | Front-to-back airflow | Front-to-back airflow |
Storage temperature | -40ºC to +70ºC (-40°F to +158°F) | -40ºC to +70ºC (-40°F to +158°F) | -40ºC to +70ºC (-40°F to +158°F) |
Long-term operating temperature | 0°C to 40°C (32°F to 104°F) | 0°C to 40°C (32°F to 104°F) | 0°C to 40°C (32°F to 104°F) |
Storage relative humidity [RH] | 5% RH to 95% RH, noncondensing | 5% RH to 95% RH, noncondensing | 5% RH to 95% RH, noncondensing |
Long-term operating relative humidity [RH] | 5% RH to 85% RH, noncondensing | 5% RH to 85% RH, noncondensing | 5% RH to 85% RH, noncondensing |
Storage altitude | ≤ 5000 m (16404 ft.) | ≤ 5000 m (16404 ft.) | ≤ 5000 m (16404 ft.) |
Long-term operating altitude | ≤ 5000 m (16404 ft.) (When the altitude is between 1800 m and 5000 m (5906 ft. and 16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).) | ≤ 5000 m (16404 ft.) (When the altitude is between 1800 m and 5000 m (5906 ft. and 16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).) | ≤ 5000 m (16404 ft.) (When the altitude is between 1800 m and 5000 m (5906 ft. and 16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).) |
MTBF [year] | 34.93 | 34.55 | 32.68 |
MTTR [h] | 1 | 1 | 1 |
Availability | 0.99999717 | 0.999997158 | 0.999997075 |
MTBF [year] | 34.93 | 34.55 | |
MTTR [h] | 1 | 1 | |
Availability | 0.99999717 | 0.999997158 | |
Maximum number of 100GE ports | 144 | 288 | |
Maximum number of 40GE ports | 144 | 288 | |
Maximum number of 10GE ports | 192 | 384 | |
Maximum number of GE ports | 192 | 384 | |
PoE | Not supported | Not supported | |
Maximum power output capability (including the system power output and PoE power output) [W] | 5+1 backup: 3000 W x 5 = 15000 W 6+0 backup: 3000 W x 6 = 18000 W | 9+1 backup: 3000 W x 9 = 27000 W 10+0 backup: 3000 W x 10 = 30000 W |
